0.5HP MINI MAGIC SELF PRIMING PUMP
FinishedGoodsRG Item Code: FGRG-0028
UOM : PCS
Self Priming Pumps are manufactured as per IS: 8472. These Self priming Domestic Pumps are light in weight with rugged construction design and balance parts which give noiseless operation for a longer duration.
| HP/kW | 0.5/0.375 |
| Stage | 1 |
| Phase | SP |
| Voltage (V) | 240 |
| Speed (RPM) | 2800 |
| Suction (mm) | 25 |
| Delivery (mm) | 25 |
| Head (m) | 18 |
| Discharge (lpm) | 15 |
| Head Range (Meter) | 13 - 20 |
- Longer product life
- Value for money
- 100% cost recovery in just 30 months
- High Discharge & Suction
- Wide Voltage Range
- Easy to install, easy to start
- Efficient energy saving
.png)
| Motor Body | Made from Extruded Aluminum/Pressure Die-casted and cast iron for better heat dissipation. |
|---|---|
| Stator | Vacuum Impregnated and epoxy coated for corrosion resistance. Thick end laminations are provide to protect motor windings. |
| Rotor | Aluminum Die Cast Rotor |
| Stamping | Electrical Steel High Grade For Better Performance. |
| Windings | Enameled insulated EC Grade copper |
| Bearings | High-carbon chromium steel Pre-lubricated double-shielded Ball bearing with high load bearing capacity. |
| Impeller | High Tensile Bronze |
| Suction Casing & Flange | High Grade CI FG 260/200 Cast Iron. |
| Suction Casing & NRV | Cast Iron Grade CI FG 260 |
| Shaft | AISI 420/410 Stainless Steel of adequate diameter to ensure rigidity and ground to close tolerances. |
| Mechanical Seal | Nitrile-butadiene rubber, Resin Carbon, Ceramic for High Sealing Solution. |
