FinishedGoodsLCM Item Code: FGLCM-0052


Latteys Centrifugal Monoblack Pumps are manufactured as per IS: 8079. These pumps and impellers are specially designed to get the best hydraulic efficiency. At the same time, the totally enclosed fan-cooled system is suitable for conditions where there is a wide voltage fluctuation

HP/kW 3/2.25
Stage 1
Phase Single Phase
Voltage (V) 240
Speed (RPM) 2840
Suction (mm) 75
Delivery (mm) 75
Head (m) 10
Discharge (lpm) 700
Head Range (Meter) 6 - 13
  • Longer product life
  • Value for money
  • 100% cost recovery in just 30 months
  • High Discharge & Suction
  • Wide Voltage Range
  • Easy to install, easy to start
  • Efficient energy saving

Motor Body Cast Iron Grade CI FG 260
Stator Vacuum Impregnated and epoxy coated for corrosion resistance. Thick end laminations are provide to protect motor windings.
Rotor Aluminum Die Cast Rotor dynamically balanced for Vibration free smooth operation.
Stamping Electrical Steel High Grade For Better Performance.
Windings Enameled insulated EC Grade copper
Bearings High-carbon chromium steel Pre-lubricated double-shielded Ball bearing with high load bearing capacity.
Impeller Cast Iron Grade CI FG 260 High quality abrasion resistant Impeller dynamically balanced.
Volute Cast Iron Grade CI FG 260
Shaft AISI 420/410 Stainless Steel of adequate diameter to ensure rigidity and ground to close tolerances.
Pressure Tank Imported tanks are meant to assure safe working and prolonged operational consistency.
